Hot Selling Inclined Copper and Brass Tube Induction Brazing Machine

This specialized induction brazing machine features a 15-40kW high-frequency power supply with IGBT inverter technology, optimized for copper-to-copper and copper-to-brass joints in refrigeration systems. The machine incorporates custom-designed elliptical and helical induction coils that precisely conform to evaporator, condenser, and compressor geometries, including complex U-bends and header connections. A fully integrated water cooling system maintains optimal operating temperatures during continuous production runs. The modular design includes a rotary positioning fixture with 0-90° tilt adjustment for angled tube brazing, coupled with a PLC-controlled 6-axis robotic arm for precise joint alignment. An integrated argon gas purge system ensures oxide-free brazing environments for critical refrigerant circuits.

The system achieves exceptional thermal management through dual-wavelength infrared pyrometers with ±2°C temperature accuracy, monitoring multiple joint locations simultaneously. Advanced PID algorithms dynamically adjust power output to maintain optimal brazing temperatures between 600-800°C depending on alloy composition. The rapid heating capability reaches target temperatures in 8-15 seconds, with a narrow heat-affected zone limited to 3-5mm from the joint, preventing thermal distortion of thin-walled tubing. This precision is particularly crucial for capillary tube connections in evaporators where excessive heat could cause flow restriction.

Consistent joint quality is achieved through the machine's ability to maintain uniform filler metal flow (AWS BCuP-5/BAg-8 alloys) with porosity levels below 0.5%. Destructive testing reveals joint tensile strengths exceeding base metal values by 10-15%. The process eliminates flux residues that could contaminate refrigerant circuits, meeting ASHRAE 15 and UL 207 safety standards. Automated vision inspection systems verify joint completeness and fillet formation, achieving first-pass yield rates of 99.2% in production environments.

Designed for high-volume manufacturing, the machine completes a typical 3/8" tube-to-header joint in 18-25 seconds, enabling throughput of 140-180 joints per hour. Quick-change coil assemblies reduce setup time to under 5 minutes when switching between different component geometries. Energy consumption is 40-50% lower than torch brazing systems, with power factor correction maintaining 92% energy efficiency. The rugged construction supports 24/7 operation with MTBF exceeding 8,000 hours, while predictive maintenance alerts minimize unplanned downtime.

For compressor applications, the system includes special fixtures for hermetic terminal brazing with controlled thermal profiles to prevent motor winding damage. Condenser coil brazing utilizes multi-coil arrays for simultaneous header-to-tube joints, reducing cycle times by 30%. Evaporator production benefits from micro-brazing capabilities for capillary tube connections as small as 1/8" OD. All configurations include refrigerant-compatible nitrogen purging systems and meet ISO 5149 safety requirements for flammable refrigerant applications. The machine's data logging capability provides complete traceability for each brazed joint, recording 20+ parameters for quality assurance documentation.
