Ultra High Frequency Induction Welding Unit for Brazing Steel Tube Induction Heating Machine
product description
Hongye produced advanced induction heating system delivers fast, localized heating for precision joining of metals. Using high-frequency electromagnetic induction (10–400 kHz), it instantly heats workpieces without direct contact, ensuring clean, oxidation-free welds, brazed joints, or solder connections. Ideal for steel tubes, copper pipes, and other conductive materials, it offers adjustable power (10–100 kW) for various thicknesses and alloys. Energy-efficient and controllable, it minimizes heat distortion while achieving strong, repeatable bonds. Suitable for automotive, HVAC, and industrial manufacturing, this machine supports automated production with rapid cycle times and consistent quality. Perfect for high-speed brazing, soldering, and welding applications.
Application scope
This ultra high-frequency induction heating system is engineered for precision joining applications across multiple industries. Its primary application is in the brazing and welding of steel tubes for HVAC, automotive exhaust systems, and industrial piping, where it ensures leak-proof, high-strength joints with minimal oxidation. The machine is equally effective for soldering copper pipes in refrigeration and plumbing systems, delivering fast, localized heating without damaging sensitive components.In the electrical industry, it enables precise soldering of terminals, connectors, and busbars. For aerospace and defense, it facilitates the brazing of high-performance alloys in turbine components and heat exchangers. The automotive sector benefits from its ability to braze aluminum heat exchangers and weld transmission components with repeatable quality. Additionally, it supports jewelry manufacturing by enabling delicate soldering of precious metals. With adjustable power (10-100kW) and frequency (10-400kHz), the system accommodates various material thicknesses and production volumes, making it ideal for both small workshops and high-speed industrial lines. Its energy-efficient operation reduces costs while maintaining superior joint integrity.
Configuration and Performance
This advanced induction heating system features a robust power supply unit (10-100kW) with IGBT/SiC-based inverter technology, ensuring stable high-frequency output (10-400kHz) for precise thermal control. The machine integrates a water-cooled induction coil system with customizable geometries to match specific workpiece shapes, coupled with a precision positioning fixture for accurate joint alignment. A closed-loop temperature regulation system with infrared/pyrometer feedback maintains ±5°C accuracy, while the PLC/HMI interface enables programmable heating profiles for different materials and joint types.
Performance-wise, the machine achieves rapid heating rates up to 200°C/sec, reducing cycle times to 3-15 seconds per joint depending on material thickness. Its localized heating minimizes thermal distortion, preserving base material properties within 2mm of the joint zone. The system maintains 85-92% energy efficiency through resonant circuit design, significantly outperforming flame or resistance heating methods.
For welding applications, it produces full-penetration steel tube welds with tensile strength matching base metal (100% joint efficiency). In brazing, it ensures uniform filler metal flow (AWS Class A quality) with porosity <1%. The soldering mode delivers oxide-free copper joints with electrical conductivity >98% IACS standard.
The machine supports both manual and automated production, featuring robotic arm compatibility for inline integration. Safety systems include overcurrent/overvoltage protection, emergency stop, and interlocked enclosures meeting ISO standards. Optional argon/nitrogen purge systems prevent oxidation for reactive metals.
Ideal for high-mix production, the system stores 100+ programs for different parts/materials. Its modular design allows quick coil changes (<5min) and power upgrades. With MTBF exceeding 10,000 hours and <0.5% downtime, this solution delivers industry-leading reliability for critical joining applications in aerospace, energy, and precision manufacturing sectors.
Technical specifications
UHF-03 05 06 |
Specification |
Max Input Power |
3KW 5KW 6KW Customizable |
Oscillation Frequency |
0.5-2MHZ |
Output Current |
3-28A |
Input Voltage |
Single phase AC 220V, 50/60Hz |
Cooling Water Requirements |
0.2Mpa, 3-5L/min |
Duty Cycle |
80%(3KW 5 KW), 100%(6KW) |
Optional Configurations |
Default panel has no timing function, timing function machine is optional |
application Scenarios:
